IPSO DR30SLG - Front Panel and Door Assembly; Thermostat Assembly

Page 50
Parts—30 lb. Dryer (Front of Dryer)
1 TU7733 #8X1/2" Self Drill Screw
2 TU1771 #6 Twin Nut
3 TU1979 Door Switch
4 TU1770 Insulator
5 TU2373 Switch Bracket
6 TU3219 #6 x 1" S.M.S.
7 TU10010 Jacket Welded Assembly
8 TU4937 3/8"-16 Jam Nut
9 TU3211 3/8"-16 x 2 1/2" Leveling Bolt
10 TU10290 Lint Screen Housing
11 TU10362 Lint Screen Only
TU5225 Frame Only
12 TU9035 Lock JWC2
TU2844 Key JWC2
TUB1867 Lock & Key JWC2
TU8928 Cam
13 TU14559WHT Lint Door (Specify Color)
14 TU14555 Lint Door Handle
15 SB-00949-0 Fastener, Plastic
16 TU14557 Kickplate
17 TU2620 Solid Top (Gas Model)
TU6129 Solid Top (Electric Model)
18 TU2877 #10 Speed Nut
19 TU2483 Sweep Sheet Gaskets
20 TU5887 Key
21 TU2882 1/2"-20 Hex Nut
22 TU2831 1/2" Split Lockwasher
23 TU10651 Cover Plate (Steam)
24 K20 Spider Replacement Kit
25 TU10284 Lint Trap Front Support
26 TU10177 Spacer
27 TU8457 Thermostat Cover
28 TU9225 Coin Vault, Lock and Key
29 TU14602 Front Panel and Door Assembly
(Specify Color)
30 TU2083 Basket Welded Assembly
TU7188 Basket/Spider Assembly
31 TU2883 1/2" Cut Washer
32 TU2313 Tie Rod
33 GA-00765-0 Direct Spark Igniter
TU14176 “CE” Direct Spark Igniter
TU14675 Australian Direct Spark
Igniter
34 *TU9111 Thermostat Assembly
(Coin Meter Model Only)
35 GA-00803-0 Cable, Hi-Voltage DSI
36 TU7690 Insulation
39 SB-00836-0 Screw, Phillips, Pancake Head
40 TU8152 Insulation—US Model Only
41 TU7735 Insulation—US Model Only
42 TU8108 Insulation—US Model Only
43 TU7736 Insulation—US Model Only
45 P104 1/4" Washer (Pkg of 6)
46 TU9384 Adjustment Strip
47 TU3479 #10-32 x 7/16" Truss Head
Screw
48 TU2842 Hex Nut
50 TU2878 #10 x 5/8" Screw
* See separate page for exploded view.
(51- 53 Not Shown)
51 CA-00841-0 Label - Clean Lint Trap
52 CA-00655-0 Trim - Rubber Insert
53 TU2853 Gasket - Lint Door
