iQe SIMPLICITY 25 - Page 47

),
107 A 6322358 25 - LPG
107 B 6322350 30 - MET
107 C 6322352 30 - LPG
107 D 6322353 35 - MET
107 E 6322354 35 - LPG
108 6322306 25 - MET
108 A 6322308 25 - LPG
108 B
6322300 30 MET / 35 LPG
108 C 6322302 30 - LPG
108 D
6322303
35 - MET
109 6267119 Nozzle locking bracket
110 6278812 Air-gas hose upper side
111 6227436 C.H. return pipe
112 6277422 Pipe connecting gas valve-mixer 25
112 A
6277421 Pipe connecting gas valve-mixer 30
112 B
6277423 Pipe connecting gas valve-mixer 35
113 6266074 Sealed chamber rear panel
120 6226457 O-ring 12bis diam. 16x1,90
121 6319680 D.H.W. Technyl manifold group
122 6319681 C.H. Technyl manifold group
123 6157649 Pressure relief valve drain pipe
6211793 Hydr.group Bitron caps kit exp
6319145 9 pole female cable connector 25-30
6323815 14 pole cable connector 25-35
6316295 4 pole cable connector CN9 30
6323816 14 pole female cable connector 30
5185143 Conversion kit to LPG
5185144 Conversion kit to LPG
5185145 Conversion kit to LPG
Products reference:
8109517 - 8109518 - 8109519
Check the correspondence with the boiler data plate.
Position Code
Description
Model
Hexagonal nozzle diam. 2,60
Hexagonal nozzle diam. 3,80
Hexagonal nozzle diam. 2,90
Hexagonal nozzle diam. 4,00
Hexagonal nozzle diam. 3,00
Round nozzle diam. 2,40
Round nozzle diam. 1,90
Round nozzle diam. 2,80
Round nozzle diam. 2,20
Round nozzle diam. 3,50
5197121 Complete control panel
6316202 Connector 4 poli CN6
6316203 Connector 4 poli CN4
6316204 Connector 8 poli CN7
6316213 3 pole cable connector CN14
6316274 4 pole cable connector CN9
6316280 4 pole cable connector CN12
6316282 5+4+2 pole cable connector
5189040 Valve pack and jig kit
6127214 Main cable L=1500
6186587 Ionisation electrode cable
6319699 Split pin kit for hydraulic group
6319698 O-ring kit for hydraulic group
6281534 Gaskets kit
6319695 Murelle-Format-.....o-ring kit
5198695 Technyl hydraulic group
