Iridium 9603 SBD Transceiver Product Developers Guide
Revision 3.1
Proprietary & Confidential Information
Distribution of guide restricted to product developers only • Information contained in this guide is subject to change without notice.
3 Electrical Interfaces
The following subsections contain information for the electrical interfaces of the 9603/9603N SBD Transceiver for the non-RF
connections. The RF interfaces are covered in section 4 4.
3.1 User Connector
The user connector provides the following connections to the 9603/9603N module:
DC power supply input
Power on/off control
Serial data interface
Network available output
Supply power indicator output
3.1.1 User Connector Type
The connector on the 9603/9603N is a Samtec low-profile header connector, part number ST4-10-2.50-L-D-P-TR. Data sheets on
these connectors can be found at: http://www.samtec.com
A suitable motherboard female socket that matches this connector is the SAMTEC header part number SS4-10-3.00-L-D-K-TR.
