5: APPENDICES
Iridium Pilot™ Installation Guide 37
Environmental Specications
Above Decks Equipment ADE Enclosure Type RF Transparent dome with
aluminum base
Temperature Range -30 to + 70 degrees Celsius
(operating) -40 to +85 degrees
Celsius (Storage)
Relative Humidity 0 to 93% Relative Humidity
Precipitation Meets IPX6 resistance to high
pressure spray
Wind In excess of 100 mph with proper
mounting (see section 12)
Below Decks Equipment BDE Enclosure Type IP33 compliant plastic enclosure
Temperature Range 0 to +50 degrees Celsius
(operating) -40 to +85 degrees
Celsius (Storage)
Physical Description
ADE Diameter 57 cm
Height 20 cm
Weight 12.5 kg
Mounting Mounting bolts are M10 arranged
in a 15 cm diameter bolt circle
BDE Length 250 mm
Width 190 mm
Height 55 mm
Weight 1.35 kg
Mounting Wall mount (see attached
template in appendix C)
Power Module Length 140 mm
Width 59 mm
Height 35 mm
Weight 1 kg
Interconnect Cable Length 45 meters
Diameter 8 mm
ADE Connector Bulgin PX0728/S 9-way (IP68)
BDE Connector Shielded RJ-45 8-position
