5: APPENDICES
Iridium Pilot™ Installation Guide 43
Figure 17. BDE Drill Template
FPO FOLD OUT
223.3 mm
77.6 mm
170.5 mm
TOP BOTTOM
BDE Drill Template Use template to drill mounting (3 total) screw holes. Ensure template scale is 1 to 1. Check all dimensions before drilling to the wall.
