BB067Installation Guide
©Copyright 2022 Ironman 4x4 Pty Ltd. No part of this publication may be reproduced or replicated without the prior written consent of Ironman 4x4 Pty Ltd
Bolt Tension Chart
Property Class TORQUE ma
NOMINAL DIAMETER - COARSE THREAD
M6 M 8 x 1 M 10 x 1.25 M 12 x 1.5
8.8
Nm 10.5 25 49 88
ft/lb 7.7 18 36 64
Bull Bar Parts List
1. Bull Bar
QTY-1
2. Mounting Bracket
QTY-1
3. Steel Skid Plate
QTY-1
4. Steel Skid Plate L-R
QTY-2
5. Support Bracket 1 L-R
QTY-2
6. Support Bracket
QTY-2
7. License Plate Bracket
QTY-2
8. Skid Plate Bracket
QTY-2
9. Bolt M12x1.25x90mm
QTY-4
10. Bolt M10x1.25x40mm
QTY-14
11. Bolt M12x1.25x40mm
QTY-7
12. Bolt M6x1.0x25mm
QTY-2
13. Bolt M8x1.25x25mm
QTY-17
14. Bolt M8x1.25x25mm
QTY-2
15. Logo
QTY-1
16. STL Bottle Opener
QTY-1
