1 - LCD Display
2 - Control Dial - Select controller programming and
operating functions.
Control Dial Positions:
Auto - Dial position for automatic operation.
Date/Time - To set the current date and time.
Water Days - To select individual days of the
week for automatic watering.
Odd/Even - To set an Odd or Even
watering day (date) schedule.
Interval - To set a Day Interval watering
schedule.
Start Times - To set start times(s) for automatic
watering program.
Stations
- To set station run time duration.
Manual Station(s) - To select station(s) for
manual operation.
Manual Programs - To select watering
programs for manual operation.
Special Functions - To select optional controller
functions.
Test - To run a test program to check station
operation.
OFF - Turns off and prevents all station operation.
3 - Sensor Switch - Active/Bypass switch to control
operation of an optional rain sensor.
4 - Sensor Connection Terminals
5A- Plug-in Transformer Connection Terminals
(indoor models only).
5B- Power Connection Wires (outdoor domestic and
Australian models only)
5C- Power Connection Terminals (outdoor international
models only).
6- and Buttons - Press to increase or decrease
display number values and various manual functions.
7 - Button - Press to select program A, B or C.
8 - Button - Press to advance to next portion of
program information or next station when operating.
9 - Station Terminals - Connection terminals for valve
control wires, master valve or pump start relay wires.
10 - Plug-in Transformer (indoor models only) - Supplies
24 V a.c. power to the controller from a grounded
wall plug outlet. (Domestic model shown.)
11 - Symbol - Displayed when setting an automatic
watering program start time.
12 - Symbol - Displayed when watering is on or set.
The
symbol indicates no watering is set.
13 - Station Numbers - Displayed when setting program
start time(s) and while a station is running.
14 -
Symbol - Displayed 30 seconds when charging
back-up power to retain program memory.
15 - Today/ Symbol - Displayed when setting a Day
Interval schedule. The
symbol is shown when a
language other than English is selected.
16 - Symbol - Displayed when setting the station run
time duration.
17 - % Symbol - Displayed when a Watering Budget run
time duration adjustment is in use.
18-
Main Display - Shows various time values and
controller information.
19 -
A B C - Program letter identifiers displayed during
programming and operation.
20 - Reset Contacts - Momentarily connect the contacts
with a metal conductor such as the tip of a flat
screwdriver to reset all programming parameters to
the factory default settings.
