Congratulations. You have purchased the easiest-to-use landscape control system
available today. Please read through this guide before you begin installing or
programming your Rain Dial Plus controller.
Your Rain Dial Plus package includes:
Outdoor models Indoor models
• Controller • Controller
• 2 keys • Plug-in transformer (domestic models only)
• 3 mounting screws • 3 mounting screws
• Installation & Programming Guide • Installation & Programming Guide
• Mounting template • Mounting template
• One 9-volt alkaline battery • One 9-volt alkaline battery
(domestic models only) (domestic models only)
Specifications
Outdoor Models (Internal Transformer):
• Input: 120 V a.c., 60 Hz, 30 VA (domestic), 230 V a.c., 50 Hz, 30 VA (export)
240 V a.c., 50 Hz, 30VA (Australia)
Indoor Models (External Transformer):
• Input: 24 V a.c., 60 Hz, 30 VA (domestic) or 24 V a.c., 50 Hz, 30 VA (export and
Australian) Note: Plug-in transformer supplied with domestic models only.
All Models:
• Output: 24 V a.c. at 1.0A total maximum output; 0.5A maximum per station
• Master Valve/Pump Start Relay Output: 24 V a.c. at 0.375A (maximum)
• Operating temperature range: 32˚F to 140˚F (0˚C to 60˚C)
• Battery back-up: One 9-volt alkaline
Rain Dial Plus controllers, manufactured on or after October 4
th
, 2000 (date code
100400 or later printed in the battery compartment) or marked with the “R/R” symbol
are “Remote Ready.” The optional KwikStart system allows remote activation
of the controller from as far as 160 feet to 100 yards away. The KSR-KIT,
connected to your Rain Dial Plus controller allows you to remotely run the
valves while out in your yard or garden for system “checkout”, fall air
“blowout” in freeze-prone areas or system troubleshooting.
Contents & Specifications
3
New Freature: Remote Control Compatibility
