ISA T2000 - Phase Angle

DOC. SIE10110 Rev. 6 Page 13 of33
OUTPUT
RANGE
RESOLUTION
ACCURACY
HIGH AC CURRENT
19.99 A
20 mA
± (0.5% + 50 mA)
199.9 A
200 mA
± (0.5% + 400 mA)
999 A
1 A
± (0.5% + 1 A)
LOW AC CURRENT;
10 A
1.999 A
1 mA
± (0.5% + 5 mA)
19.99 A
10 mA
± (0.5% + 20 mA)
LOW AC CURRENT;
40 A
7.999 A
4 mA
± (0.5% + 20 mA)
79.99 A
40 mA
± (0.5% + 80 mA)
VOLTAGE OF LOW
AC CURRENT
19.99 V
20 mV
± (0.5% + 50 mV)
99.9 V
100 mV
± (0.5% + 200 mV)
HIGH AC VOLTAGE;
3000 V
199.9 V
200 mV
± (0.5% + 0.5 V)
1999 V
2 V
± (0.5% + 4 V)
2999 V
3 V
± (0.5% + 6 V)
CURRENT OF HIGH
AC VOLTAGE
19.99 mA
50 uA
± (0.5% + 200 uA)
199.9 mA
200 uA
± (0.5% + 500 uA)
0.999 A
1 mA
± (0.5% + 2 mA)
LOW AC VOLTAGE
250 V AC
19.99 V
20 mV
± (0.5% + 50 mV)
199.9 V
200 mV
± (0.5% + 400 mV)
299.9 V
300 mV
± (0.5% + 600 mV)
CURRENT OF LOW
AC VOLTAGE
19.99 mA
20 uA
± (0.5% + 50 uA)
199.9 mA
200 uA
± (0.5% + 400 uA)
1.999 A
2 mA
± (0.5% + 4 mA)
LOW DC CURRENT
199.9 mA
100 uA
± (0.5% + 200 uA)
1.999 A
1 mA
± (0.5% + 2 mA)
19.99 A
10 mA
± (0.5% + 20 mA)
I IMPULSES
19.9 A
0.1 A
± (5% + 0.5 A)
NOTES:
- The change range is the actual value at which the range is changed. This avoids saturation
problems when we have to measure fast-changing values.
- Metering temperature coefficient: ± 0,05%/°C of the value ± 0,02%/°C of the range.
3.5.2 Phase angle
- Readings, resolution and accuracy: see table.
MEASUREMENT
RANGE
RESOLUTION
ACCURACY
PHASE
0 - 360
1°
1° ± 1 DIGIT *
* Specified accuracy applies to outputs greater than 10% of the selected range.
- Phase angle temperature coefficient: ± 1 ppM/°C of the value.
