ISA T2000 - High AC Voltage; Low AC Voltage; Other Features of Main Outputs; Auxiliary Contact

DOC. SIE10110 Rev. 6 Page 10 of33
- Type of waveform: R-C discharge; polarity: positive.
- Current range: from 0 to 10 A peak.
- Repetition rate: a pulse every 3 s.
- Output connection: two safety sockets.
3.2.5 High AC voltage
- Type of generator: variable transformer and high voltage transformer.
- Output characteristics: see table below.
VOLTAGE
OUTPUT
V
CURRENT
OUTPUT
A
OUTPUT
POWER
VA
LOAD
TIME
Min
RECOVERY
TIME
min
3000
2500
0.2
0.6
600
1500
STEADY
1
-
8
- Output connection: two H.V. safety sockets.
3.2.6 Low AC voltage
- The AC voltage is isolated from the high AC current.
- AC voltage range: 250 V.
- Available power and duty cycle: see table below.
- Connection: two safety banana sockets.
RANGE
V AC
VOLTAGE
OUTPUT
V
OUTPUT
POWER
VA
LOAD
TIME
min
RECOVERY
TIME
min
250
250
125
STEADY
-
220
250
3
9
3.2.7 Other features of main outputs
- Zero crossing control. Main AC outputs are generated and stopped as the output waveform is zero.
This implies that in mode ON+TIME the output drops to zero with a delay from 0 to one cycle after
STOP is detected.
- Over-current alarm message.
- Thermal protection: by NTC. The operator is alerted by a message.
- Output adjustment: from less than 5% to 100% of the output.
- Output measurement. The used output is software selected; the selected socket is confirmed by a
light.
3.3 AUXILIARY CONTACT
- Possibility to delay the auxiliary contact switch with respect to test start. Delay range: from 0 to
99.99 s.
- Contacts range: 5 A; 250 V AC; 120 V DC
