ISA T2000 - Optional High Voltage Output 1200 V; Codes PII30110 (Supply 230 V) or PII40110 (Supply 110 V); Model T2000 E, Code PII50110; Transit Cases

DOC. SIE10110 Rev. 6 Page 24 of33
Other output characteristics do not change with the power supply.
NOTE: the 110 V supply changes also the characteristics of the BU2000 option: see the description
for details.
3.12.2 Optional high voltage output 1200 V; codes PII30110 (supply 230 V) or
PII40110 (supply 110 V)
The high voltage generator can optionally have the following characteristics, that are better suited
for the case of 5 A nominal secondary current. This option is to be specified at order.
VOLTAGE
OUTPUT
V
CURRENT
OUTPUT
A
OUTPUT
POWER
VA
LOAD
TIME
Min
RECOVERY
TIME
min
1200
1000
0.5
1.5
600
1500
STEADY
5
-
20
3.12.3 Model T2000E, code PII50110
The model must be specified at order.
This model allows to perform high current tests with more power. It is based upon the 1200 V high
voltage generator.
The corresponding features of the high current output are the followings.
CURR.
A
MAX
POW.
VA
MAX
ON TIME
s
OFF
TIME
min
MAX
TOTAL
LOAD
mOhm
CABLE
LENGTH
m
LOAD AT
CABLES
END
mOhm
POWER AT
CABLES
END
VA
100
850
CONT.
-
86
10
80
800
150
1200
15 min
30
55
10
49
1100
200
1550
4 min
15
39
10
33
1320
300
2050
15
5
23
6
20
1800
400
2400
15
5
15
4
12
1920
600
2600
5
3
7
0.5
6
2160
800
2100
1
2
3
0.5
2
1280
NOTE: The table shows the maximum cable length, and the maximum load and power at the end of
the connection cable.
Connection cables.
- N. 2 High current connection cables, 95 sq. mm, 0.5 m long. Terminated on one side with an high
current connector to T2000, and on the other side with a ring terminator.
- N. 4 High current connection cables, 95 sq. mm, 4 m long. Terminated on both sides with a ring
terminator.
- N. 4 High current connection cables, 95 sq. mm, 6 m long. Terminated on both sides with a ring
terminator.
NOTE: this allows reaching a total of 20 m, 95 sq. mm, or 10 m, 190 sq. mm.
- N. 2 high current connection vices, rated 800 A maximum.
. Instrument weight: 37 kg.
3.12.4 Transit cases
