DOC. SIE10110 Rev. 6 Page 23 of33
5. N. 2 High voltage connection cables, 4 m long, 5 kV, with earth screen. Terminated on one side
with an HV connector, and on the other side with a safety banana plug.
6. N. 2 Low current connection cables, 10 sq. mm, 4 m long. Terminated on one side with the high
current connector, and on the other side with a 4 mm banana plug.
7. N. 4 Clamps to connect low voltage or low current or measurements.
8. N. 1 Cable for low voltage measurement connection, shielded, 10 m long. Terminated on one
side with the measurement connector, and on the other side with two clamps.
9. N. 1 Cable for the 600 V measurement connection, shielded, 10 m long. Terminated on one side
with three 4 mm banana plugs, and on the other side with two clamps.
10. N. 1 Grounding cable, 8 m long, terminated on one side with a 4 mm banana plug, and on the
other side with an earth connection clamp.
11. N. 4 Crocodiles for measurements connections (2 red, 2 black).
12. N. 4 Measurement inputs cables (4 cables: 2 red and 2 black), 2 m long, terminated on both sides
with a 4 mm banana plug.
13. N. 1 Connection Cables Transport case.
3.11 OTHER CHARACTERISTICS
- Interface: serial RS232; baud rate 57600 baud
- Mains supply: 230 V ± 15%; 50-60 Hz, OR 110 V ± 15%; 50-60 Hz; to be specified at order.
- Maximum supply current: 16 A.
- The instrument comes complete with the following items:
. User’s manual;
. Spare fuses (no. 5), T16A;
. Set of connection cables, included in a suitable transport case with wheels and handle.
- Dimensions: 455 (W) * 325 (D) * 290 (H) mm.
- Weight: 31 kg.
3.12 OPTIONS
3.12.1 Power supply code PII20110
This option is to be specified at order.
- Mains supply: 110 V ± 15%; 50-60 Hz.
- Maximum supply current: 16 A.
With this power supply voltage, the high current maximum output power is limited as shown in the
following table.
