Iskra MT440 - 6.9 Mechanical; 6.10 Environmental conditions; 6.11 Dimensions

Technicaldata
38 User’sManual
6.9 Mechanical
Dimensions W100 × H75× D105 mm
Max. conductor cross section for
terminals
2,5 mm2 with pin terminal
4 mm2 solid wire
Vibration withstand 7g, 3 … 100 Hz, 1 oct/min
10 cycles in each of three axes
Shock withstand 300g, 8ms pulse
6 shocks in each of three axes
Mounting Rail mounting 35 × 15 mm
acc. to DIN EN 50 022
Enclosure material PC/ABS
Flammability Acc. to UL 94 V-0
Housing protection IP20
Weight 370 g
6.10 Environmental conditions
Ambient temperature usage group III
-10 … 0 … 45 … 55 °C
Acc. to IEC/EN 60 688
Operating temperature -30 to +70 °C
Storage temperature -40 to +70 °C
Average annual humidity
≤
93% r.h.
Altitude
≤
2000 m
6.11 Dimensions
