39
SPEED: 1/1, 1/2, 1/3, 1/6, 1/12, 1/25,
1/50, 1/75, 1/100, 1/120, 1/150, 1/215,
1/300, 1/425, 1/600, 1/1000, 1/1250,
1/1750, 1/2500, 1/3500, 1/6000,
1/10000s.
IRIS PRI: Gain and shutter speed value are
adjusted automatically according to working
environment; Iris value is adjustable
manually.
IRIS: F14, F11, F9.6, F8, F6.8, F5.6, F4.8,
F4, F3.4, F2.8, F2.4, F2, F1.6, CLOSE.
BRIGHT PRI: Manually adjust the video
brightness.
BRIGHT: 0, 1, 2, 3，4, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22,
23, 24, 25, 26, 27.
EXP-COMP: Once EXP-COMP is set as On,
below level options become available -7, -6,
-5, -4, -3, -2, -1, 0, +1, +2, +3, +4, +5, +6, +7
+7 is the maximum compensation value for
bright, -7 is the maximum compensation
value for dark.
BLC: ON, OFF.
Backlight compensation (BLC) is video gain
done automatically to correct the exposure
of subjects that are in front of a bright light
source.
ANTI-FLICKER (OFF, 50Hz, 60Hz): To
avoid video flicker at power systems of
different frequency.
FV BRIGHTNESS: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9,
10, 11, 12, 13, 14.
COLOR
COLOR menu is used to adjust color related
values. Available options:
WB MODE: AUTO, ATW (auto tracking),
ONE PUSH, INDOOR, OUTDOOR,
MANUAL, SODIUM LAMP, FLUO LAMP
“ONE PUSH”: In “ONE PUSH
TRIGGER” mode, aim the camera at a
pure white object (say a white paper),
then press OK button.
“AUTO” mode: R.GAIN, G.GAIN and
B.Gain can be chosen from -7~+7.
“MANUAL” mode: R.GAIN and B. GAIN
value can be chosen from 0~255.
SATURATION: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10,
11, 12, 13, 14.
HUE: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12,
13, 14.
< COLOR>
WB MODE MANUAL
R.GAIN 7
B.GAIN 7
SATURATION 7
HUE 7
SELECT BACK
