Ismart LTC-A2001NV2 - Annex 1 Technical Specifications; Tracking Camera Specifications

42
ANNEX 1 TECHNICAL SPECIFICATIONS
LENS
Tracking Camera
Image Sensor
1/2.8” CMOS, 2.14MP
Lens
4.7mm-94mm
Iris
F1.6-F3.5
Optical Zoom
20X
Digital Zoom
12X
Angle of view
59.5°-2.9°
Focus
Auto/Manual/ One push trigger
Min. Illumination
0.5 Lux (30FPS), 0.1Lux (60FPS)
Shutter
1/1 ~ 1/10,000 sec
Gain
Auto/ Manual
White Balance
Auto, Indoor, Outdoor, One push, Manual
Exposure
Auto, Manual, Shutter Priority, Iris Priority
S/N Ratio
≥50dB
Full-view Camera
Image Sensor
1/2.8” CMOS
Effective Pixels
2.14MP
White Balance
Auto
Exposure
Auto
Focus
Manual
Focal Length
3.4mm
Angle of view
Horizontal: 72°, Vertical: 40°
Network
Resolution
Max Support 1920*1080@60fps
Video Compression
H.265/ H.264
Audio Compression
AAC
Network Protocol
ONVIF, RTSP,HTTP, TCP,UDP,RTMP
IE access
Support
Multi-stream
4 streams: 2 for tracking camera,
2 for wide angle camera
