43
PTZ
Pan Range
-170°~+170°
Tilt Range
-30°~+90°
Pan Speed
0.1°~120°/s
Tilt Speed
0.1°~90°/s
Preset Number
256
Comm. Port
RS-485, RS-232
WIFI interface
2.4G/ 5G WIFI (optional)
Debug / upgrade interface
100M RJ45, POE optional
Protocol
PELCO-D, VISCA
SDI Video
Video Output
HD-SDI (2 Channels)
Video Format
1080p60, 1080p50, 1080p30, 1080p25, 1080i60，
1080i50, 720p60, 720p50
General
OSD
Yes
Power Input
DC12V
Power Consumption
<20W
Working Temp
0℃~+40℃
Storage Temp
-20°C~+60℃
Dimensions
225mm×163mm×212mm
Weight
1.96KG
Color
Grey
Blackboard Writing Sensor
Sensor
1/3”CMOS
Effective Pixel
400 mega pixel
Min Illumination
1Lux
S/N Ratio
＞50dB
Gain Control
Auto
E-Shutter
1/30-1/10000
White Balance
Auto
Focal Length
2.4mm
FOV
Horizontal: 90°; Vertical: 50°
IRIS
F2.0
Video Compression
H.264
