Iso-Tech IDM63N - Page 10

9
(2) AC Volts
Range Accuracy Over voltage protection
3V
* ±(1.5%reading + 5digits)
600V DC or 600V rms
30V
±(1.5%reading + 5digits)
40Hz to 500Hz
300V
600V
Resolution
1mV
10mV
100mV
1V
* Frequency Response : 40Hz ~ 300Hz for 3V Range.
Input Impedance : 10MΩ //less than 100PF.
The reading will fluctuate approximately 2 ~ 5 counts over 200V.
