BATTERY REPLACEMENT
The meter is powered by a two 1.5V battery. Refer to Figure 2 and use the following procedure to replace the
battery:
1. Disconnect the test leads and turn the meter off. Remove the test leads from the input terminals.
2. Position the meter face down. Remove the screw from the case bottom.
3. Lift the end of the case bottom until it gently unsnaps from the case top at the end nearest the input terminal.
4. Lift the battery from the battery box.
5. Fit the new battery into the battery box.
6. Replace the case top and case bottom. Reinstall the screw.
