Isokern Standard 36 Installation, Operation, Maintenance And Owner's Manual

10
Assembled Firebox Dimensions - Models 60 & 72
Model
Minimum Framing
60”
76 1/2” W x 87 1/2” H x 29½” 2500 lbs.
72”
B
28”
28”
D
38”
38”
H
25 ¼”
25 ¼”
I
4 3/4”
4 3/4”
J
5”
5”
K
8”
8”
TOP PLATE
Part
No.:
M77
Fireplace
Size:
60” W
Quantity:
2
25 ¼”
11”
4 ¾”
N
M
Right SectionFront Elevation
Top Plan View
Plan Section
F
69 3/4”
57 1/4”
M
14 1/4”
14 1/4”
N
11”
11”
32 3/4”
A
85 1/2 ”
73 1/2”
C
85 3/4 ”
85 3/4”
E
69”
G
55 1/2“
65 1/2”
C
D
H G
I
K
F
E
E
B A
J
B
M77 72” W2
81 1/4”
Weight
88 1/2” W x 87 1/2” H x 29½” 2900 lbs.
O
55 1/2”
65 1/2”
O
**FOR SPECIFIC CLEARANCES TO COMBUSTIBLES, PLEASE REFER TO RATING PLATE ON PAGE 7.
3”

Isokern Standard 36 Specifications
