Isokern Standard 36 Installation, Operation, Maintenance And Owner's Manual

Name: Isokern Standard 36
Brand: Isokern
Rating: 4 (1 reviews)

72 pages

To Next Page

To Previous Page

DM 54 Chimney System - 60 & 72”

NOTE: The maximum installed height of the Isokern DM 54 system on the models 60 & 72 dual chimney system is 22’ without

additional structural support.

* BKE Report dated March 30, 2011

22’-0” *

Table of Contents2
General Information3
Intended Use Statement4
Safety Instructions5
Warnock-Hersey Listing Label7
Assembled Firebox & Smoke Dome Dimensions8
Component List & Dimensions9
Assembled Firebox Dimensions 60 & 7210
Component List & Dimensions 60 & 7211
Required Clearance to Combustibles12
Rough Framing Dimensions & Corner Location Layout13
Assembly Instructions15
Access Modification18
Firebrick Installation19
Flush Wall Finish Detail20
Assembly Instructions - 6022
Assembly Instructions - 7227
DM 54 Chimney System - 60 & 7231
Required Clearances (When Sheathing Protrudes Beyond Front of Firebox)32
Required Clearance to Combustible Framing33
Required Clearances to Insulation and Vapor Barriers34
Flush Wall Fire Brick Finish Detail35
Flush Wall Brick Finish Detail36
- Interior Masonry Veneer Fireplace Finishes & Clearances37
- Masonry Veneer Construction Details38
Non Combustible Finished Facing Requirements & Clearance to Combustible Trim39
Concrete Support40
DM Chimney System41
- General Information41
- Component List & Dimensions42
Component Weights43
- Installation44
- Lateral Support45
- Lateral Support46
- Offset Block47
- Offset Block50
- Brick Ledge Installation51
- Brick Ledge Load Capacity52
- Crown Caps53
Height Requirements54
- Structural Information55
- Common Chimney Terminations56
- Class a Metal Flue57
Specialty Applications58
- Two Story Stacked Installations58
Fire-Lite Application General Information60
- Fire-Lite Application - Required Clearance to Combustibles61
- Fire-Lite Application - Combustible Floor System62
- Fire-Lite Application - Raised Metal Platform63
Fire-Lite Application - Flush Wall Finish Detail65
FTF-13 or Equivalent Chimney System66
FTF-13 or Equivalent Installation Components68
Summary69
Notes71
