Flush Wall Fire Brick Finish Detail
Recommended Fire Brick Detail: When drywall is the wall nish at the MAGNUM face and ush with the rough face of the
MAGNUM rebox and damper beam, it is recommended when installing the required re brick lining to the interior of the rebox,
that the leading edge of the re brick - at the oor and at the side walls of the rebox - be set ush with the MAGNUM’s rough
rebox front. This will aid in the overall t and nish of the MAGNUM replace front when the code required noncombustible
nished facings are applied.
This alignment of re brick application, as shown above (Figure 76), allows the re brick lining to be in the same plane with the
room’s wall nish surface. With the re brick set in this fashion the noncombustible nish facing material can be set tight against
the leading edge (or, “room edge”) of the re brick at the sides of the replace opening. At the same time the nished facing material
can lay at against the room’s nished wall surface.
FIGURE 76
Drywall Flush With
Firebox Front
Noncombustible
Facing Material
