ISON IS-DG500 Series User Manual

42
| af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4
| cs5 | cs6 | cs7 | ef | va } } <0~1> to { <0-63> | { be | af11 | af12 | af13 |
af21 | af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 |
cs4 | cs5 | cs6 | cs7 | ef | va } }
Parameter
Name
Description
<0~7>
Cos level
<0-63>
Dscp level
be
Default PHB(DSCP 0) for best effort traffic
af11~13
Assured Forwarding PHB 11~13(DSCP
10,12,14)
af22~23
Assured Forwarding PHB 22~23(DSCP
20,22)
af31~33
Assured Forwarding PHB 31~33(DSCP
26,28,30)
Af41~43
Assured Forwarding PHB 41~43(DSCP
34,36,38)
cs1~7
Class Selector PHB CS1~7 precedence
1~7(DSCP 8*(cs value))
ef
Expedited Forwarding PHB(DSCP 46)
va
Voice Admit PHB(DSCP 44)
<0~1>
Specific drop precedence level
3.10.8 qos map dscp-ingress-translation
Description
Configure dscp ingress-translation
Syntax
qos map dscp-ingress-translation { <0~63> | { be | af11 | af12 | af13 | af21
| af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4
| cs5 | cs6 | cs7 | ef | va } } to { <0-63> | { be | af11 | af12 | af13 | af21 |
af22 | af23 | af31 | af32 | af33 | af41 | af42 | af43 | cs1 | cs2 | cs3 | cs4 |
cs5 | cs6 | cs7 | ef | va } }
Parameter
Name
Description
<0~7>
Cos level
<0-63>
Dscp level
be
Default PHB(DSCP 0) for best effort traffic
af11~13
Assured Forwarding PHB 11~13(DSCP
10,12,14)
af22~23
Assured Forwarding PHB 22~23(DSCP
20,22)
af31~33
Assured Forwarding PHB 31~33(DSCP
26,28,30)
Af41~43
Assured Forwarding PHB 41~43(DSCP
34,36,38)
cs1~7
Class Selector PHB CS1~7 precedence
1~7(DSCP 8*(cs value))
ef
Expedited Forwarding PHB(DSCP 46)
va
Voice Admit PHB(DSCP 44)
<0~1>
Specific drop precedence level
3.10.9 qos policer
Description
Configure qos policer
Syntax
qos policer <unit> [ fps ] [ flowcontrol ]
Parameter
Name
Description
