Page 39 of 40
Dual Furnace Models M17705, N17706 & 17707 Iss.09 – 12/14
FIGURE 2; SEALED METAL FREEZING POINT CELL
A High-purity graphite crucible and cover
B High-purity graphite sleeve
C High-purity metal
D Fused-quartz envelope, filled to give a pressure of 1 standard atmosphere at the metal freezing temperature.
