www.istorage-uk.com
5
diskAshur DT
Button Panel
The “Cancel” button can be used to:
Cancel current operation•
Return to the previous step when you knowingly entered a wrong •
password
Exit the Admin Mode•
The button can be used to access the diskAshur DT and it can also be used
as an OK acknowledgement in the following operations:
Entering a password•
Conrming a new password•
The indicator light displays the following colors to indicate the various modes of
operation:
RED: Standby Mode•
BLUE: Admin Mode•
GREEN: User Mode•
The indicator light has other display methods to indicate different status of the
diskAshur DT. Details are provided later in this chapter.
3
1
2
Cancel button
button
Indicator lights
