iSystem iC5000 Hardware Reference

 iSYSTEM, October 2016 4/69
iC5000 Debug/Trace Module (JTAG/BDM)
iC5000 Base Unit in conjunction with the iC50020 Debug/Trace module is a universal on-chip emulation
platform. Additionally, a connecting cable (40-pin flat cable), a target specific cable adapter and architecture
specific license is required to debug the target based on a specific architecture.
Valid input voltage range for all debug signals is between 1.8 - 5.5V
Note: Typically, IC50000 and IC50020 modules already come assembled together when delivered to the user.
The user only needs to connect a specific cable adapter via 40-pin flat cable, through which the development
system then connects to the target.
iC5000 development and test system including also an optional IO module
Ordering code
IC50020

iSystem iC5000 Specifications
