PARTS LIST
PART NO. DESCRIPTION PART NO. DESCRIPTION
8 Seal 43 Rubber sleeve
9 Spring 44 Latch
10 O-ring 36.3 x 2.5 45 Spring
11 O-ring 15.7 x 2 46 Front plate
12 Valve 47 Spring pin
13 O-ring 33.5 x 3.5 48 Spring pin
14 Stopped washer 49 Screw
15 O-ring 48.5 x 2.5 50 Drive guide
16 Collar 51 Rail
17 O-ring 28.3 x 3 52 Pin
18 Piston assembly 53 Movable magazine
19 O-ring 27.3 x 2 54 Stopped plate
20 Cylinder 55 Screw
21 Bumper 56 Feeder shoe
22 Body 57 Spring
23 Joint guide 58 Fixed magazine
24 Safety guide 59 Screw
25 Spring 60 Pin
26 Safety bracket assembly 61 Support
27 Spring pin 62 Screw
28 Seal 63 Torsion spring
29 Trigger valve head 64 Lock
30 Spring 65 Nut
31 O-ring 5.5 x 1.5 66 Soft grip sleeve
32 Trigger valve stem 67 O-ring 40.2 x 2.3
33 O-ring 15 x 1.9 68 End cap
34 Trigger valve guide 69 Air plug
35 Trigger spring
WARRANTY
Please refer to schematic drawing page 15
ITC branded power tools, air nailers staplers and compressors are designed for use in DIY (do-it-yourself), light or
intermittent duty, semi-professional applications. They are not intended for use in professional, production, industrial or
continual use applications.
ITC makes every effort to ensure that its products meet high quality and durability standards and are warranted for two
years against manufacturers’ faults and defects for a period of two years from the date of purchase to the original owner.
ITC will REPAIR OR REPLACE (at our discretion) merchandise deemed by the company to be defective, provided that it
is has not been misused, abused, altered, or repaired by anyone other than an authorized repair centre.
Please consult the ITC catalogue or your nearest ITC distributor to determine those products that are covered by our over-
the counter warranty. Any ITC tool that fails during normal use and within the specied warranty period and qualies for
over-the counter warranty must be returned to its point of purchase for replacement or credit. Any item not listed as over-
the-counter warranty must be shipped, prepaid freight, to an authorized repair depot accompanied by a copy of the invoice
specifying the date that the item was purchased. Returned tools that are not accompanied by a proof of purchase (Copy of
Invoice) will not be repaired or replaced under warranty.
This warranty does not extend to normal wear or consumable parts such as brad and staple gun driver blades, grinding
discs, saw blades, driver bits, electric motor brushes, worn chords, etc. It also does not apply to ITC tools used in
professional, production, industrial or continual use applications.
For a listing of the authorized repair centers please refer to the ITC catalogue.
