Technical Specification
11 Technical Specification
This chapter will introduce the main technical parameters of this instrument,
such as rated voltage/current/power and so on. Besides, we will introduce the
working environment and storage temperature.
♦ IT-M3412
♦ IT-M3422
♦ IT-M3432
♦ IT-M3413
♦ IT-M3423
♦ IT-M3433
♦ IT-M3414
♦ IT-M3424
♦ IT-M3434
♦ IT-M3415
♦ IT-M3425
♦ IT-M3435
11.1 IT-M3412
Source Parameter
Rated value( 0 ℃-40
℃)
Output Voltage
0-60V
Output Current
-30A~30A
Output Power
-200W~200W
Min. operating voltage
6V at -30A
CC
Range
-30A~30A
Setup Resolution
10mA
Accuracy
≤0.1%+0.1%FS
CV
Range
0-60V
Setup Resolution
1mV
Accuracy
<0.1% Umax
Internal Resistance
(CV Priority mode)
Range
0-1000mΩ
Setup Resolution
0.1mΩ
Accuracy
2%*Rmax
CP
Range
-200W~200W
Setup Resolution
0.1W
Accuracy
<1.0% Pmax
