Function and Features
Copyright © Itech Electronics Co., Ltd. 19
Chapter III Function and Features
This chapter will introduce the basic operation of IT6700 series power
supply,including the following subdivisions:
Switching of local/remote operation modes
Voltage setup
Current setup
Output on/off operation
Setup value/actual value switching
Voltage/current/power adjustment
Save/recall operation
Trigger operation
Menu operation
OVP protection function
Key lock function
Remote sense function
3.1 Switching of local/remote operation modes
Local button can enable you switch mode from remote to local mode.
After you power on the power supply, the power supply’s default mode is local
mode, all the buttons can be used in this mode. While in remote mode, you
can’t operate through front panel directly except Meter and Local keys. Local
and remote mode can be controlled through PC. In addition, the mode
changing will not influence the output parameters.
3.2 Voltage Setup
You can set voltage within the range of rated voltage value. When you press
button, the button will be lit. This indicates that you can set voltage.
There are three ways to set output voltage through front panel.
The first way: press , adjust cursor location through
button, pressing and will enable you to adjust the setting voltage
value.
The second way: press , adjust cursor location through
button, adjust rotary knob to change the setting voltage value.
The third way: press button and number key( to ) to set
voltage value
3.3 Current Setup
You can set current within the range of rated current value. When you press
button, the button will be lit. This indicates that you can set current.
There are three ways to set output current through front panel.
The first way: press ,adjust cursor location through
