ITech IT7321 - Page 50

Specification
Copyright © Itech Electronics Co., Ltd. 42
Accuracy
±(1%+0.36A)
Temp. coefficient
±(0.05% per degree from 25℃)
Power
Resolution
L:0.01W
M:0.1W
H:1W
Accuracy
L:±(0.2%+0.2W) (47HZ-65HZ)
M:
±
(0.2%+2W) (47HZ-65HZ)
H:±(0.2%+10W) (47HZ-65HZ)
Temp. coefficient
±(0.05% per degree from 25℃)
GENERAL
Memory
10 memories
Sync Output Signal
Output Signal 5V,BNC type
Interface(Option)
LAN,USB,RS232,GPIB
Operation Environment
0-40℃/20-80%RH
Dimension 19" 3U
Weight 48Kg
Model IT7324H
INPUT
Phase 1
Voltage
220Vac±10% or 110Vac±10%
Frequency 47-63Hz
Max.Current 30A(220Vac) or 60A(110Vac)
Power Factor 0.7(typical)
AC OUTPUT
Max.Power 1500VA
Max Current(rms)
0-250V 6A
0-500V 3A
Max Current(peak)
0-250V 18A
0-500V 9A
Phase
1Φ/2W
Total Harmonic Distortion(T.H.D)
≤1% at 45-500Hz (Resistive Load)
Crest Factor 3
Line Regulation
0.1% max for a ±10% line change
Load Regulation
≤0.5%FS(Resistive Load)
Response Time <100uS
SETTING
Voltage Range 0-500V High, 250/500V Auto
