Overview
Copyright ©ITECH Electronic Co., Ltd. 9
z Master-slave parallel with current sharing technology, up to 960kVA,
z Intuitive touch screen; Built-in single/3-phase AC power meter; Scope
function
z Fast response time and high accuracy 0.1%+0.2%FS
z waveforms Library: Sine wave, Square wave,Triangle wave,Clipped sine
waves,Staircase wave, self-defined waves
z Harmonics and Interharmonics waveform synthesizer
z Power line disturbance simulation testing by LIST
programming/SWEEP/Surge&Sag functions
z The harmonic measurement function can measure 50th order harmonics of
voltage and current.
z Output 0-360 ° start/stop phase angle can be set
z AC, DC, AC+DC or DC+AC output capability
z Comprehensive working modes selectable: single-phase ,three-phase,
reversed phase and multi-channel
z Programmable Output Impedance, allows simulation of Real-World Utility
Grid Impedance.
z compliance tests incl LVRT /Phase Jump/Frequency variation /Harmonic
Injection
z Supported regulatory testing include IEC61000-4-11/4-13/4-14/4-28 etc.
z Front panel USB port for data and waveform import and export
z Provides various trigger input/output signals. When amplitude/frequency
changes, trigger signals can be generated to synchronously capture the
current waveform of DUTs
z Relay CTRL function, to cut off the connection between instrument and DUT
z Frequency lock and phase lock function, tracking the external signal
frequency and phase, to achieve 6 phase& 12 phase power output
z Built-in USB/CAN/LAN/Digital IO interface, optional GPIB /Analog&RS232
1.2 Models and Options
