ITech IT8511A+ User Manual

Quick Start
Copyright © Itech Electronic Co., Ltd. 14
2.4 Front Panel Keys
( Blue-green)
The Shift composite button is used in combination
with other buttons to implement the functions
marked under these buttons.
(Gray)
Local button is used to switch local and remote
mode.
(Gray-white)
Power on/off button.
~
Enter the digits 0 to 9.
Decimal point
The escape button
Select the constant current mode and set the input
current value.
0
9
ESC
IT8516C+ Model
① Power switch
② Vacuum fluorescent display (VFD)
③ Compound key and the local switch key
④ Number key:
Set the parameters value, achieve the
menu’s function by key combination
⑤ Function key:
Set the operation mode
Control the input state: On/Off
⑥ Direction function
⑦ Rotary knob
⑧ Input terminal
