ITech IT8600 Series

Technical Specifications
Copyright © ITECH Electronic Co., Ltd. 85
Input power
0-5400W
Frequency
45~450Hz
CC mode *1
Range
0.3~60Arms
Resolution
2mA
Accuracy
±(0.1%+0.2%FS)
CR mode *2
Range
1Ω~833Ω
Resolution
16bit
Accuracy
0.2% +0.02S
CP mode
Range
5400W
Resolution
0.4W
Accuracy
0.5%+0.5%FS
Crest Factor(CF)
(CP,CC mode)
Range
1.414~5.0
Resolution
0.005
Accuracy
(1.5% / Irms) + 1% FS
Power Factor
(PF)
Range
0~1 lead or lag
Resolution
0.001
DC Section
Rating value
Input voltage
10~600V
Input current
0.3~60A
Input power
0-5400W
Working mode
CC,CP,CR
Short circuit
simulation
The max. power point or max. current in CC mode
Meter
Current
Range
0-180A
Resolution
1mA
Accuracy
0.2%+0.2%FS+0.2%*CF^2*KHZ
Voltage
Range
0-600V
Resolution
10mV
Accuracy
0.1%+0.1%FS
Meter(Continue)
Other parameter
S(VA),Q(VAR),P(W),Ip+,Ip-,Freq,THDv,CF,PF,R,FFT
Other
Voltage Monitor
±600v/±10V(Isolated)
Current Monitor
±180A/±10V(Isolated)
Protection
OCP:63Arms,OVP:430Vrms,OPP:5500 W,OTP:85℃
Interface
GPIB, USB, LAN
Dimension
side plate structure: 483.00mm (W)*482.34mm(H)*641.08mm(D)
cabinet: 550.0000mm (W)*801.40(H)*807.5mm(D)
Weight
side plate structure: 98KG
cabinet: 145KG
AC Input
Voltage
100-240V AC
Frequency
47-63Hz
Power
450VA
Parameter of each
phase
IT8617 (AC/DC Load) V1.2
Three-Phase Mode
Delta or Star connection type are supported of IT8617.The connection
depends on user’s testing requirement.
AC Section
Parameter
Input voltage
50~420Vrms, 600V peak
Input current
0~20Arms, 60A peak
Input power
0-1800VA
Frequency
45~450Hz
