iTechworld iTECHDCDC25 - Page 16

16
DCDC Chargers
General Rating
Model iTECHDCDC25 iTECHDCDC40
Vehicle Input Voltage 9V – 32V
Solar Input Voltage 10V – 32V
Max Input Current 25A 45A
Input Fuse Rating 40A 60A
Continuous Output Current Up to 25A Up to 40A
Output Fuse Rating 40A 60A
Minimum Auxiliary Battery Charge
Start Voltage
4V
Standby Current <10mA
Battery Type Lithium LiFePO4, Lead Acid, Gel, AGM, and Calcium
Operating Temperature -20°C ~ 80°C
IP Rating IP67
Weight 670g 950g
Dimensions (LxWxH) 150 x 127 x 39mm 188 x 127 x 39mm
Battery Capacity 50-500Ah 80-800Ah
Output Rating
Charge Type 3-Stage
STD Gel AGM Calcium LiFePO4
Absorbtion (Maximum Output Voltage) 14.4V 14.1V 14.7V 15.3V 14.5V
Float Voltage 13.4V 13.5V 13.4V 13.6V
Input Rating
Input Turn On Turn Off
12V Standard Alternator >13.2V <12.8V
24V Standard Alternator >26.2V <25.6V
12V Smart Alternator
(Ignition Cable Connected)
>12V <11.8V
24V Smart Alternator
(Ignition Cable Connected)
>24V <23.6V
Solar >16V 2A <15.8V 1.5A
