iTechworld iTECHDCDC25 - Specifications

15
Control Hub
Dimensions (LxWxH)
403 x 304 x 116mm
403 x 304 x 119mm
Inputs/Outputs 4 x 50A Anderson plugs
Inputs
1 x 3-pin 50A Anderson plug (DCDC Alternator Input)
1 x 50A Anderson plug (DCDC Solar Input)
SPECIFICATIONS
Battery Monitor
Model iTECHBM500
Supply Voltage 10V-100V
Battery Capacity 10Ah-999Ah
Maximum Measured Current 500A
Power Consumption (Screen Off) <2mA
Power Consumption
(Screen Brightness @ 10%)
<20mA
Power Consumption
(Screen Brightness @ 100%)
<60mA
Voltage Accuracy ±1%
Current Accuracy ±1%
Capacity Accuracy ±1%
Operating Temperature -20°C ~ 80°C
Exterior bracket dimensions (LxWxH) 106 x 81 x 18mm
Mounting bracket points (LxW) 95 x 70mm
Monitor backing dimensions (LxWxH) 80 x 59 x 16mm
IP Rating IP20
Outputs
2 x 12V 15A cigarette lighter outputs
USB-C Output
3 x fast charge USB Outputs
Dimensions with DCDC (LxWxH)
