8
Connect the spade terminal to the bottom blank tab on your switch and
using a phillips head screwdriver, connect the negative ring terminal to
one of the spare screw positions on the negative bus bar.
Tuck cables in under the Control Hub lid, lowering the lid carefully onto
the Control Hub, ensuring the lid is oriented correctly. Fasten the 4
provided screws, being sure not to over-tighten.
5.
6.
