13
GENERAL SPECIFICATIONS
BATTERY SPECIFICATIONS
Model name PS3600 PRO
Dimensions 550*321*464mm
Weight 42Kg
Capacity 3840Wh
Max parallel capacity 11,520Wh
XT90 Input 12-160V 2000W max
AC output 50/60Hz (frequency switch available), rated at
3600W Pure Sine Wave. Built in overload and
short circuit protection.
USB QC3.0 2 x 18W
USB-C 3 x 20W
USB-C 100W
DC 5521 output 2 x 12V/3A
XT-60 output 12V/25A
Cigarette lighter output 12V/10A
Power off current <500uA
Operating temperature -10~40°C
Environment humidity ≤90%RH
Cycle life >3500 times
Battery type LiFePO4
Single cell rated voltage 3.2V
Single cell rated capacity 20Ah
Battery pack rated voltage 48V
Battery pack output voltage 40V-54V
Battery pack rated capacity 3840Wh
