9
UPS MODE
The PS3600 PRO has a bypass function, which means power will not pass through
the battery; it will be taken directly from the AC output.
In this mode, the power source is the power grid, when there is an emergency
power outage, the power source will switch to the battery within 1Oms and protect
the connected appliance.
UPS CONNECTIONS:
As shown in the gure below, connect the PS3600 PRO between the wall socket
and the electrical appliances, ensuring the power of the PS3600 PRO is ON. When
you turn on the electrical appliances, power will be taken directly from the grid.
In this state, when the power grid is cut off, it will automatically switch to the
PS3600 PRO internal battery to supply power.
• In UPS mode, the maximum power output is 3600W.
• In UPS mode, if the AC output exceeds 3600W, the AC overload symbol
will illuminate.
