Control Codes PcOS Series 150 Programmer's Guide
Summary by Code
Page 82 Rev G 12/14/99
[ESC] 4 1BH,34H &%TF Set top of form. 20
[ESC] 5 <n> 1BH,35H &%CA {n=0}
&%MA {n=1}
Set auto line feed.
n=0 end
n=1 begin
21
[ESC] 8 1BH,38H &%PF Disable paper error sensor. 51
[ESC] 9 1BH,39H &%PO Enable paper error sensor. 51
[ESC] : 1BH,3AH &%F2 Set 12 cpi. 31
[ESC] < <n> 1BH,3CH &%PT Set print suppress and pass
through.
57
[ESC] =<n1>
<n2>
<start
code>
<data>
1BH,3DH Download character font image. 28
[ESC] > <n> 1BH,3EH Enable custom character set.
n=0 Off
n=1 On
16
[ESC] ?
<m><n>
1BH,3FH Reassign graphic mode. 46
[ESC] A <n> 1BH,41H Set variable line spacing to n/72.
Where n=1..85 is enabled by
[ESC] 2.
19
[ESC] B <n
1
>
<n
2
><n
3
>
...<n
i
>
<0>
1BH,42H Set vertical tab stops. 20
[ESC] C <n> 1BH,43H &%SL <m
1
><m
2
> Set form length in lines. 21
[ESC] C [NUL]
<n>
1BH,43H &%SI <m
1
><m
2
> Set form length in inches. 21
[ESC] D<n
1
>
<n
2
><n
3
>
..<n
i
><0>
1BH,44H Set horizontal tab stops. 16
[ESC] E 1BH,45H &%MM Begin emphasized print. 37
[ESC] F 1BH,46H &%CM End emphasized print. 37
[ESC] G 1BH,47H &%ME Begin enhanced print. 37
[ESC] H 1BH,48H &%CE End enhanced print. 37
[ESC] I <n> 1BH,49H &%QT {n=0}
&%QU {n=1}
&%QL {n=2}
&%QS {n=3}
Select print mode.
n=0 High Speed Draft
n=1 Utility
n=2 NLQ Courier
n=3 NLQ Sans Serif
22
[ESC] J <n> 1BH,4AH &%FM
<m
1
><m
2
><m
3
>
Do a fine line feed. 18
[ESC] K <n>
1
<n>
2
1BH,4BH Set single-density graphics (60h x
72 v dpi).
45
[ESC] L <n>
1
<n>
2
1BH,4CH Set double-density half-speed
graphics (120 h x 72 v dpi)
45
[ESC] P <n> 1BH,50H &%RF {n=1}
&%RI {n=2}
&%RN {n=0}
Set rotated font.
n=0 normal
n=1 rotated 90°
n=2 rotated 270°
[ESC] R 1BH,52H &%HV Reset horizontal and vertical tab
stops.
17
[ESC] S <n> 1BH,53H &%SB {n=1}
&%SP {n=0}
Select superscript/subscript.
n=0 superscript
n=1 subscript
38
[ESC] T 1BH,54H &%SE End superscript/subscript. 38
