ITRON Axonic User Manual

4
L1
L2
A1
A2
D1
B
F2
L
D
K
F1
For further technical data, refer to table:
Type
DN65 qp25 DN80 qp40 DN100 qp60 DN150 qp150
PN16 PN25 PN40 PN16 PN25 PN40 PN16 PN25 PN40 PN16 PN25 PN40
Body Length
(available versions)
L1 mm 200
300
300 300 200
225
300
350
300 350 250
360
400
360 400 300
500
500 300
Electronic L2
B
mm
mm
124
119
124
119
124
119
124
119
124
119
124
119
124
119
124
119
124
119
124
119
124
119
124
119
Height A1
A2
mm
mm
204
93
204
93
204
88
209
100
209
100
209
100
219
111
219
118
219
112
244
143
244
150
244
144
Bolt Circle
Diameter
K mm 145 145 145 160 160 160 180 190 190 240 250 250
Bolt holes
Diameter
L mm 19 19 18 19 19 18 20 23 22 24 28 26
Number of holes 4 8 8 8 8 8 8 8 8 8 8 8
Flange Dimensions D
D1
F1
F2
mm
mm
mm
mm
185
108
-
-
185
108
-
-
188
109
178
175
200
128
-
-
200
128
-
-
203
120
194
190
220
156
-
-
235
156
-
-
238
149
228
224
285
216
-
-
300
216
-
-
300
203
288
288
Weight (length) kg
(mm)
8,0 (200)
9,0 (300)
9,0 (300) 10,5 (300) 9,3 (200)
9,6 (225)
10,4 (300)
10,9 (350)
10,4 (300) 14,0 (350) 13,0 (250)
14,0 (360)
15,0 (400)
16,0 (360) 20,0 (400) 24,0 (300)
28,0 (500)
31,0 (500) 32,0 (300)
* Flanges PN16 and PN25 according EN 1092-2 / Mobile Flanges Elevated interface type B
** Flanges PN40 according EN 1092-1 / Type 21 PN40 Male hubbed socket Type E
