ITV ICE MAKERS SPIKA Series User Manual

SERVICE MANUAL SPIKA
17
Digital outputs
Digital inputs
Analogical inputs
Symbol
Description
ESP
Thickness detection sensor
NW
Water level in reservoir
Connector for double layer stacking of 2 machines
Symbol
Description
CO1
Connector + jumper for indication of the lower machine
SYMBOL
Description
Relays amp
C
compressor (Relay / contactor)
5
B
pump
5
EW
Water inlet valve
5
GC
Hot gas valve.
5
EP
Drain valve
5
SL
Free
5
Symbol
Description
ICE
Ice position switch
Switch for 3 positions:
Ice – 0 - wash
WASH
Wash position switch
P
Safety pressure switch / NC contact
MC
Curtain micro relay contact NC
EL
Free
Dip-switch
1
Pressure reset
2
Time alarm valuation
3
Curtain micro relay contact dip-switch NC/NO
4
Water inlet valve e/w timeout
5
Free switch
