RESCUE GUIDE ‒ Technical rescue
TECHNICAL BACKUP
DRIVER AND PASSENGER COMPARTMENT
– Printed 692.68.340 – 1st Ed. 04/2015
DRIVER AND PASSENGER COMPARTMENT
Safety devices
The vehicles are equipped with various safety devices which intervene according to the type of collision.
Location of airbag and pretensioners
222679
Figure 8
1 Airbag.
2 Side collision airbag sensors.
3 Pretensioners.
4 Drop-down airbag curtain.
5 Passenger airbag.
Steering wheel adjustment
226174
Figure 9
These adjustments are carried out as follows:
● Engage the parking brake.
● Release lever .
● Grasp the steering wheel with two hands, lift it or lower it until
desired position is obtained.
● Lock lever in the position required in the steering column.
