14
RESCUE GUIDE ‒ Technical rescue
TECHNICAL BACKUP
OPENING THE ENGINE COMPARTMENT BONNET
– Printed 692.68.340 – 1st Ed. 04/2015
OPENING THE ENGINE COMPARTMENT BONNET
SV158
Figure 25
Release the engine bonnet by lifting the lever located in the lower
section of the dashboard and highlighted in the figure. This lever
releases the bonnet clip from the hook.
706941
Figure 26
From outside the vehicle, operate the lever located inside the front
grille to release the bonnet locking device (1).
RAISING THE VEHICLE WITH AIR SUSPENSION
Vehicles fitted with air suspension may be lowered or raised. The button to activate this command is situated on the dashboard.
701938
Figure 27
The button (3) (on the side panel) enables the vehicle to be
lowered.
Pressing button (1) (on the side panel) raises the back of the vehicle.
