IVT 09LR-N User Manual

12LRN
2 – 6
2.2. Printed wiring board
From 4Way Valve
From Expansion Valve
From Thermistor
From Fan Motor
From Compressor (C)(W)(Orange)
From Compressor
From Compressor (S)(U) (Red)
To Reactor(Gray)
To Terminal Board(1) (Brown)
To Terminal Board(N)
(Blue)
To Control Box (Green/Yellow)
To Terminal Board(2) (Red)
(R)(V)(White)

IVT 09LR-N Specifications

General

Brand	IVT
Model	09LR-N
Category	Heat Pump
Language	English
