6 Dimensions and clearance
6.1 C6 - C11
Fig. 5
Fig. 6
All dimensions are stated in mm.:
1 HTF (coll) in
2 HTF (coll) out
3 Cold water in
4 Electrical connections
5 Flow heating system
6 Hot water out
7 Return heating system
≥100 ≥100
≥300
1800
6 720 641 570-10.1I
6 720 641 855-32.1I
600
48
50
190
645
126 100 166 6779
5
3
7
4
211
1
2
20
800
6
