IVT Greenline E20 - Pipe and Electrical Connections in Greenline E20-E25

32
Dimensions and connections (models E20-E25)
(1) Return radiator
(2) Plug
(3) Radiator out
(4) Riser DHWH
(5) Heat transfer fluid in
(6) Heat transfer fluid out
(7) Electrical connections
(7)
Front
(1)
(2)
(3)
(4)
(6)
(5)
1500 mm
(1525 mm incl. feet)
®
(7)
®
539
®
®®
672
583
417
271
®
750
®®®®®
128 296 372 603 700
