moves to the next character. To Save the
Aircraft ID, Hold both STEP and LF for 5 sec.
END Y
Tap STEP button to exit the procedure.
Alarm Limits
Factory Set Default Limits
JPI conservatively sets the default alarm limits below Lycoming and
Continental recommendations.
Measuremen
t
Default Low
Limit
Default High Limit Example
CHT 450°F 230°C
465
CHT
OIL 90°
F
32°C 230°F 110°C
280
OIL
TIT 1650°F 900°C
1720
TIT
CLD -60°F/min. -33°C/min.
-65
CLD
DIF 500°F 280°C
525
DIF
BAT, 24 V 24V 32V
22 .4
BAT
BAT, 12 V 12V 16V
17.6
BAT
LO FUEL 45 min
00.20
H.M
LO TIME 10 gal, kg, ltr, lbs
7.2
REM
If you change the display to Celsius, be sure to change the alarm limits to
Celsius degrees. This is not done for you automatically. When an alarm is
displayed, tapping the STEP button will temporarily delete that
measurement from the sequence for the next ten minutes. When an alarm
is displayed, holding the STEP button until the word OFF appears will
delete that measurement from the sequence for the remainder of the flight.
Changing the Alarm Limits
You may prefer to set your own alarm limits Follow the procedure
outlined below to change any of the factory default settings.
For Your Safe Flight Page 47
