For Your Safe Flight ............................................. Page 25
Scan Sequence Example
Measurement
EXAMPLE
COMMENTS
EGT, CHT
EGT 1354 CHT 335
Square indicates the
cylinder being viewed
TIT
1370 TIT
Turbine Inlet
Temperature # 1
Shock Cooling
-30 CLD
Square indicates
fastest cooling cylinder
Compressor Discharge
Temperature
300 CDT
Temperature into
intercooler
Induction Air
Temperature
125 IAT
Temperature out of the
intercooler
Carburetor Temperature
-22 CRB
(Not available when
CDT is installed)
Difference between
hottest and coldest EGT
80 DIF
Square indicates most
widely deviating
cylinder
Fuel Remaining
Est. REM XX GAL
In gallons, liters,
pounds or kilograms
Fuel required to next
GPS WP or Destination
at present power
WP REQ XX GAL
Present with GPS
interface, valid signal
and way point
Fuel Reserve at next
GPS WP or Destination
Est. WP REM XX GAL
Present with GPS
interface, valid signal
and way point
Nautical Miles per Gal
ECON XX.X MPG
Present with GPS
interface and valid
signal. MPK, MPL,
MPP for dif units
Time to Empty
Est. T to E XX:XX H:M
Hours: minutes
calculated remaining
at current fuel burn.
Total Fuel Used
USD X.X GAL
Since last refueling or
trip total.
