Programs (Cycles)
Program 1 2 3 4 5
Program type Unpacked Packed Prion Rubber Textile
Sterilization temp 1134ºC 134ºC 134ºC 121ºC 121ºC
Sterilization pressure 204kPa 204kPa 204kPa 104kPa 104kPa
Sterilization 4 min 5 min 18 min 20 min 20 min
Drying 9 min 9 min 9 min 9 min 18 min
Vacuum pulses 1 vacuum 3 vacuums 3 vacuums 1 vacuums 3 vacuums
4.4 Preset programs
Program 6 7 8 9
Program type Liquids User Test B&D Test vacuum
Sterilization temp 121ºC 134ºC 134ºC 134ºC
Sterilization pressure 104kPa 204kPa 204kPa 204kPa
Sterilization 30 min 4 min 3,5 min 5 min - 5 min - 10 min
Drying 1 min 3 min 3 min
Vacuum pulses 0 vacuums 3 vacuums 3 vacuums
5. Control Panel
1 Display
2 Increase value key
3 Decrease value key
4 Program key
5 Start/Stop key
5.1 Controlling Panel
5.1.1 Integrated display
A. Display the chamber pressure, unit is: bar
B. Display the chamber temperature, unit is: ºC
C. Display the cycle situations. Please see the circumstance which is attached (Sterilizer operation cycle display chart).
D. Display the alarm error code when the sterilization gives the alarm during the working cycle, then you can check and nd the
malfunction components according to the error code.
5.1.2 Increase value key (2)
UP choosing has the functions that are used for setting down the cycle program and lling in water pump, Press this button you
can choose the following programs, and if press button for 3 seconds, the machine would enter into lling in water automatically
program, and the LCD would display the working cycle state.
5.1.3 Decrease value key (3)
DOWN choosing has the cycle program, press this button you can also choose the following programs.
1
43
2
5
