User Manual JABLOTRON 100
+
RFID card reader
allows control of the system
using segments and
user authorization using
contactless method (RFID
card/tag).
Keypad with a card reader
the user can control the
system using segments
and authorization, either
by entering a code or the
contactless method (RFID
card/tag), or a combination
of both for higher security.
Keypad with an LCD
display and a card reader
the user can control the
system using segments and
authorization, using either
a code, the contactless
method (RFID card/tag), both
code and card/tag for higher
security, or by authorizing and
using the options available on
the keypad’s LCD display.
The types of access modules and their combinations:
CONTINUOUS GREEN
UNSET | OFF
FLASHES GREEN
ENTRY DELAY
FLASHES RED
ALARM |
ALARM MEMORY
CONTINUOUS GREEN
EVERYTHING OK
FLASHES GREEN
CONTROL
FLASHES GREEN
2x EACH 2 s
MAINTANENCE
CONTINUOUS YELLOW
FAULT
FLASHES YELLOW
UNSUCCESSFUL SETTING
CONTINUOUS RED
SET | ON
FLASHES RED
ALARM |
ALARM MEMORY
CONTINUOUS YELLOW
PARTIALLY SET
CARD READER |
KEYPAD
