RETURN TO “ TABLE OF CONTENTS” JABRA NOISE GUIDE – MANUAL
8
MOUNTING  ALUMINUM TABLE STAND
A
Insert the micro USB pin and pull the
cable through tube A.
B
If the exstension tube is needed,
pull the cable through tube B.
Assemble tube A and B. Screw tube AB onto the base disc
and connect the Jabra Noise Guide to the power cable.
Screw the Jabra Noise Guide onto the tube. Mout to a flat
surface as shown below.
Please ensure that the cable comes out where
there is a hole in the disc base so the cable is not pinched.
A
B
